commeo Receive Connect
Radio receivers as Hirschmann adapter for awnings and Venetian blinds
Product information
The commeo Receive Connect with Hirschmann connection was developed for the use in blind and awning installations. The connection of the drive and the power supply can easily be made by a plug connection with the Hirschmann plug / coupling (STAS 3 / STAK 3)
PRODUCT BENEFITS
- Easy, retrospective programming – it is also possible when the executing device is already installed.
- Versatile use by adjustable receiver application.
- Automatic direction assignment after setting the runtime.
- Intermediate position can be reached from every position
- Installation in the flush‑mounted box or damp‑proof box
- Extensions for the local or central operation
- Low standby usage with < 0,5 W
Product videos
commeo Receive Connect: Connection and initial setup using a handheld transmitter
Functional examples
×
Downloads
Im Moment gibts noch nichts zu sehen...
Technical details
| Dimensions | 42 x 169 x 28 mm |
| Operating voltage | 230 V AC |
| Battery | not necessary |
| Protection class | IP 54 |
| Permitted ambient temp. | -25°C to +55°C |
| Assembly | on the headrail |
| Frequency | 868 MHz |
You can make the following products radio compatible:
Compatible controllers
