SE Pro-RC (Radio)

Roller shutter drive with obstacle detection (radio)

Product information

Especially made for roller shutters, the SE Pro and SE Pro-RC drives combines all positive features of an easy assembly, comfort and maximal protection of the roller shutter installation in just one drive.

The special motor head ensures an optimal sensibility in case an obstacle is on the way of motion. SE Pro and SE Pro-RC drives can be installed with normal safety and fixing springs.

When installed with blocking springs or burglar-proof fixations the manual setting of a lower end limit is recommended.

SE Pro and SE Pro-RC drives may not be used in installations with more than one shutter in a box.

The parallel connection of several SE Pro and SE Pro-RC drives is possible.

After setting the end limit positions an automatic rotation detection will occur.

Drives are available in series 1 (from shaft 40) and series 2 (from shaft 50). Series 1 SE Pro and SE Pro-RC drives are delivered with adapters (shaft 40) as standard. For drives of series 2 the adapters and the plug-in connecting cables need to be ordered separately.

TO CONTACT

PRODUCT BENEFITS

Automatic setting of the end limit positions: up-down-ready!
Sensible obstacle detection in the downwards direction
“Reverse function”: Release of the obstacle
Learning overload protection in upwards direction, freeze up protection
Soft approach against the box
Relief of upper end limit position
Good & favourable: Installation
with safety and fixing springs

Product videos

Initial setting of the roller shutter radio drive SE Pro-RC with a commeo transmitter

Manual initial setting (point at the lower limit, upper limit stop) of SE Pro-RC with commeo

Manual initial setting (point at the lower limit, point at the upper limit) of SE Pro-RC with commeo

Manual initial setting (point at the lower limit, upper limit stop) of SE Pro-RC with burglar-proof fixations (commeo)

Manual initial setting (point at the lower limit, point at the upper limit) of SE Pro-RC with burglar-proof fixations (commeo)

Initial setting of various SELVE radio drives SE Pro-RC with a commeo transmitter

Setting of intermediate and ventilation position at SELVE radio drives (-RC)

Resetting a SELVE radio drive into factory setting with commeo

Universal setting switch for all drives (SE, SE RC and SE SMI; 4 or 5 wires)

Downloads

Im Moment gibts noch nichts zu sehen...

Technical details

Type	SE Pro 1/6-RC	SE Pro 1/10-RC	SE Pro 2/7-RC	SE Pro 2/10-RC	SE Pro 2/15-RC	SE Pro 2/20-RC	SE Pro 2/30-RC	SE Pro 2/40-RC	SE Pro 2/50-RC
Article no.	41 12 23	41 12 43	41 31 10	41 31 30	41 31 50	41 31 70	41 31 80	41 31 90	41 32 93
Torque at rated load Nm	6	10	7	10	15	20	30	40	50
Effective shutter weight (kg) at shutter height of 1.5 m	14	25	19	25	35	45	67	88	102
Effective shutter weight (kg) at shutter height of 2.5 m	11	20	15	20	29	37	56	72	83
Shaft type	SW 40	SW 40	SW 60	SW 60	SW 60	SW 60	SW 60	SW 60	SW 60
Pulling force N	270	450	220	310	460	610	920	1230	1530
Rotation speed rpm	15	15	17	17	17	17	17	17	12
Power rating W	115	115	95	124	152	172	220	345	345
Current consumption A	0,5	0,5	0,41	0,55	0,66	0,75	0,95	1,5	1,5
Voltage V	230	230	230	230	230	230	230	230	230
Frequency Hz	50	50	50	50	50	50	50	50	50
Time of operation min	4	4	4	4	4	4	4	4	4
Protective system	IP 44	IP 44	IP 44	IP 44	IP 44	IP 44	IP 44	IP 44	IP 44
Test mark	CE	CE	CE, VDE	CE, VDE	CE, VDE	CE, VDE	CE, VDE	CE	CE
Limit switch range U	-	-	-	-	-	-	-	-	-
Outer diameter mm	35	35	45	45	45	45	45	45	45
Cable length m	3	3	0	0	0	0	0	0	3
Length L 1 mm	508	508	505	505	530	545	565	566	564
Length L 2 mm	494	494	488	488	513	528	548	549	548
Length of square fixing pivot mm	12	12	12	12	12	12	12	12	12
